150W 200W 250W 300W Monocrystalline Photovoltaic and Poly Solar Cell Solar System Solar Module Solar Panel

Basic Info.

Model NO.	150W 200W 250W 300W
Glass	White Tempered Glass
Long Lifespan	30 Years
Cell Grade	a
Cell Color	Blue Black
OEM ODM	Offered
Certificate	IEC 6173 IEC 61215 TUV Ce
Long Warranty	20years
Efficiency Degradation	20 Years-90%, 10 Years-80%
Number Cells	54PCS 72PCS 96PCS
Solar Cell Efficiency	17%-18.6%
Transport Package	Carton Wooden Case
Specification	as demands
Trademark	BR
Origin	Jiangsu
HS Code	85414090
Production Capacity	20000/Month

Product Description

150W 200W 250W 300W monocrystalline photovoltaic and poly solar cell solar system solar module solar panel
A.The specifical character

Module type	BR300
Rated Power	300Wp
Tolerance	+/-3%
Open Circuit Voltage (Voc)	36V
Short Circuit Current (Isc)	8.28A
Max.Power Voltage (Vm)	36.00V
Max.Power Current (Im)	7.66A
Temperature coefficients of Isc (%)	0.10/ºC
Temperature coefficients of Voc(%)	-0.33/ºC
Temperature coefficients of Pm(%)	-0.23/ºC
Cell efficiency(%)	≥17.64%

Overall Characteristics: - 60 Crystalline photovoltaic Cells per Module - Size: 1956×992×45mm (+/-10%) - Weight: 28 kg(+/-10%) - Glass 3.2mm tempered - EVA encapsulated - Glass Foil Sandwich Laminated - Sandblasting anodizing Aluminium frame - Hail up to 25mm diameter,80 Km/h tested - Temperature Range: -40 to +85°C - Nominal operating cell temperature (NOCT): 47°C - Module Efficiency: >= 16% - Standards: IEC-61215, IEC-61730, IP-67 Electrical connection: - Junction Box - Bypass Diodes, nominal current 10A - Solar Cable 4mm² 900mm with MC connectors - Module connection max 1000V DC in series - Limiting reverse current IR=0.2A

B. Factory & production progress show
C. Packing Delivery , Certificate and Project show
Safety in transportation and handling is assured by reinforced side bars, corners and carton base, while each module is protected by a moulded ABS stacking unit.

Packing Information
Container		20'GP		40'GP		40'HQ
Pallets per Container		12		28		28
Pallets per Container		300		700		770

D. Application1. Any large or small on-grid or off-grid solar power stations. 2. Commercial and industrial building roof-top systems 3. Resident systems.4. Any commercial or industrial ground mounting systems5. solar television, Solar power, solar heater, solar lights, Highway solar street lamp, solar car / electric vehicles, satellites, spacecraft, space solar power plant, energy saving lamp, the field of environmental protection.
E.Warranty
25 - year limited warranty of 80% power output;10 - year limited warranty of 90% power output;5 - year limited warranty of materials and workmanship
F. Other Terms and condition:
Price Term: EXW/FOB/C&F/CIF.
MOQ: 1 set.
Payment: Typically 30% by T/T as down payment, balance by T/T or L/C before shipment. Other payment way can be negotiated.
Package: Export standard plywood case or carton packing suitable for tough handling and long-distance ocean transport.
Delivery: for 2MW , goods can be ready for shipment within 30 working days.
FAQ
What kind of certification do you have?
--- Power mono from 5W to 320W&Poly 5W - 310W with TUV,IEC61215/IEC61730.CE ,Golden Sun, ISO9001:2008
What is the warranty of solar panels?
--- 10-year warranty on material and workmanship,90% power output in 10 years,80% in 25 years
Can you quote me the best price?
We need more information about your demands, such as the power/material/Qty/etc, then We can suggest the suitable type and quote the best price for you.
How do I get solar panel from BR solar and Where can I get further information?
--- Please visit our website and send us email or call us.
